Pneumatic Rotary Joints 1-Circuits to 2-Circuits
Product Description:
Features:
- Multi-circuit functionality: This pneumatic rotary joint allows for the transmission of pneumatic signals from one circuit to two separate circuits, enabling simultaneous pneumatic connections in a rotating system.
- Efficient and reliable pneumatic transmission: The rotary joint ensures efficient and reliable transmission of compressed air or gases between stationary and rotating parts, maintaining consistent pneumatic performance.
- Compact design: The rotary joint is designed with a compact form factor, allowing for easy integration into space-constrained systems without compromising functionality.
Typical Application:
- Packaging and Printing Machinery: Pneumatic rotary joints are commonly used in packaging and printing machinery where continuous rotation is required while maintaining pneumatic connection for tasks such as air-driven controls, pneumatic clamping, and actuation.
- Material Handling Systems: Pneumatic rotary joints find applications in material handling systems like indexing tables, automated conveyor systems, and robotic arms, providing pneumatic connectivity for gripping, lifting, and positioning operations.
- Rotary Indexing Machines: Pneumatic rotary joints are utilized in rotary indexing machines where accurate and reliable pneumatic signal transmission is essential for tasks such as tool changing, part feeding, and assembly operations.
Specifications:
| Pneumatic Parameter |
| NO.of Circuits | Rotor : 1Circuits Stator: 2 Circuits |
| Connection Thread Size | Rotor:Φ6mm Counterbore Rotor: M5 , 4mm |
| Pressure | -80Kpa ~ 95 Kpa |
| Transmitting media | Compressed Air |
| Roating Speed | 0~3000RPM |
Drawing for HSJ01-2(3KM09-01-01):
FAQ:
What is the maximum pressure rating of the pneumatic rotary joint?
The maximum pressure rating can vary depending on the specific model and design of the pneumatic rotary joint. It is important to review the product specifications to ensure it meets the required pressure requirements.
How many circuits does the pneumatic rotary joint support?
The number of circuits supported by a pneumatic rotary joint can vary, ranging from single-circuit designs to multi-circuit options. It is crucial to select a rotary joint that matches the desired number of pneumatic connections.
Can the pneumatic rotary joint handle different types of gases?
Pneumatic rotary joints are typically designed to handle a wide range of gases, including compressed air, nitrogen, oxygen, and other common industrial gases. However, it is recommended to verify the compatibility of the joint with the specific gas being used.
